SINOMACH CHANGLIN GYA6000LB 17 Ton Paving Width 2.5-6m 93KW Hydraulic Asphalt Paver
ASPHALT PAVER GYA600LB
Wheel type pavers are widely used,convenient for quick transition,strong maneuverability and high work efficiently.
| Traveling type | Four-wheel drive |
| Basic paving width | 2.5m |
| Max. paving width | 6m |
| Max. paving thickness | 150mm |
| Working Speed | 0-11m/min |
| Traveling speed | 0-11km/h |
| Hopper capacity | 12 t |
| Engine Manufacturer | Dongfeng Cummins |
| Engine Model | QSB3.9-C125 |
| Fuel tank capacity | 116L |
| Rated power | 93KW |
| Rated speed | 2200rpm |
| Electric system | 24V |
| Emission | State Ⅲ |
| Telescopic range | 2.5-4.5m |
| Compaction type | Single |
| Compaction frequency | 25HZ |
| Compaction amplitude | 5mm |
| Vibration frequency | 40HZ |
| Transport height | 3000mm |
FEATURES
1.Engine
Dongfeng Cummins engine is adopted for its strong power, high reliability, and excellent start-up performance at low temperatures.
2. Equipped with full hydraulic automatic telescopic screed, paving width stepless adjustable.
3.The travel drive system adopts the imported hydraulic piston pump, planetary reducer and plunger motor, which has high reliability; the closed control controls the left and right independent drive modes to ensure stable running of the track drive system, flexible steering and convenient transition.
4. Micro-computerized control is easy and convenient, closed cycle design is much more stable and practical.humanized control panel design makes your operation more easy and comfortable.
FAQ
1.Why Choose Us?
CHANGLIN WEA s Committed To Offer Not Only Products With High Quality And Performance And Competitive
Price, But Also In-Time Delivery And Comprehensive 7*24 After-Sale Services.
2.What is the product range of our factory ?
World Equipment is a large-scale machinery manufacturing enterprise primarily specializes in supplying excavator,wheel
loaders,palm oil tractor and related attachments. We can also customize non-standard products according to customer's
requirements.
3.What payment terms can we accept?
Normally 30% deposit is required in advance, 70% balance shall be settled before shipment. And 100% irrevocable L/C at sight
with the terms we agreed can also be accepted.
4. What Certificates do we have?
All products meet with the ISO9001 Quality System and have acquired CE certificate. and also EPA approval will be available if
needed.
5. How about the delivery time?
About standard products, we always have in stock and can
deliver immediately. But customized products will take more time, depending on the requirements of the order.
